ForceLED
Luminaria compacta estanca IP66 con difusor prismático exclusivo y controles inalámbricos integrados.
- LEDs de alta eficiencia(~120lm/W) que reducen el consumo de energía y los costes. Mayores ahorros por largos ciclos de mantenimiento.
- Controles de regulación integrados por detección de presencia para un mayor ahorro energético.
- Grado de estanqueidad IP66.
- Carcasa robusta de aluminio completamente reciclable.
- OTRAS OPCIONES DISPONIBLES (regulación, emergencia…). Consulte las opciones de configuración en myProduct.
Materiales y acabados
Canopy: aluminium
Diffuser: UV stabilised polycarbonate with linear prisms
Gasket: Silicone sponge
Toggles: stainless steel
Quick fix bracket: stainless steel
Instalación y montaje
Para montaje de superficie, suspendido y BESA. Todas las luminarias incluyen soportes de fijación rápida para montaje de superficie y hay juegos de accesorios opcionales para ayudar con las demás opciones de montaje.
Especificación
Texto para especificación:
Luminaria LED compacta de alto rendimiento de estanqueidad IP66, a prueba de polvo o humedad con cuerpo de aluminio completamente reciclable, exclusivos difusores de policarbonato prismático y pestañas de acero inoxidable, motor de luz LED que ofrece 4.150 y 6.150 lm, Ra80, 4000K, larga vida útil de 50.000 horas.
Como ForceLED de Thorn Lighting
▼ ForceLED productos configurados
Descripción | Potencia de la luminaria (W) | Salida lumínica (lm) | Tipo | Peso (kg) | Código SAP | ||||
---|---|---|---|---|---|---|---|---|---|
FORCELED 4000 HF MWS L840 | 34 | 4150 | LED | 2.70 | 96242077 | ||||
FORCELED 4000 HF QC L840 | 34 | 4150 | LED | 2.80 | 96241953 | ||||
FORCELED 4000 MWS RF L840 | 34 | 4150 | LED | 3.13 | 92900127 | ||||
FORCELED 4000 MWS TW QC L840 | 34 | 4150 | LED | 3.00 | 92900118 | ||||
FORCELED 4000 RF L840 | 34 | 4150 | LED | 3.04 | 92900124 | ||||
FORCELED 4000 RF QC L840 | 34 | 4150 | LED | 4.00 | 92900107 | ||||
FORCELED 4000 TW L840 | 34 | 4150 | LED | 3.04 | 92900134 | ||||
FORCELED 6000 HF MWS L840 | 53 | 6300 | LED | 2.70 | 96242081 | ||||
FORCELED 6000 HF QC L840 | 53 | 6300 | LED | 2.80 | 96241954 | ||||
FORCELED 6000 HF TW L840 | 53 | 6300 | LED | 2.70 | 96617239 | ||||
FORCELED 6000 HF TW QC L840 | 53 | 6300 | LED | 2.80 | 96617240 | ||||
FORCELED 6000 MWS RF L840 | 53 | 6300 | LED | 8.50 | 92900109 | ||||
FORCELED 6000 MWS RF QC L840 | 53 | 6300 | LED | 8.50 | 92900108 | ||||
FORCELED 6000 RF L840 | 53 | 6300 | LED | 8.50 | 92900110 |
▼ ForceLED productos configurados, regulable
Descripción | Potencia de la luminaria (W) | Salida lumínica (lm) | Tipo | Peso (kg) | Código SAP | ||||
---|---|---|---|---|---|---|---|---|---|
FORCELED 4000 HFI L840 | 34 | 4150 | LED | 2.60 | 96242079 | ||||
FORCELED 6000 HFI L840 | 53 | 6300 | LED | 3.49 | 92900116 |
▼ ForceLED productos configurados, emergencia
Descripción | Potencia de la luminaria (W) | Salida lumínica (lm) | Tipo | Peso (kg) | Código SAP | ||||
---|---|---|---|---|---|---|---|---|---|
FORCELED 4000 E3 MWS L840 | 34 | 4150 | LED | 2.00 | 92900126 | ||||
FORCELED 4000 E3 RF L840 | 34 | 4150 | LED | 2.40 | 92900125 | ||||
FORCELED 4000 HF E3 L840 | 34 | 4150 | LED | 4.60 | 96241952 | ||||
FORCELED 4000 HF E3 MWS RF L840 | 34 | 4150 | LED | 4.70 | 96617236 | ||||
FORCELED 6000 E3 RF L840 | 53 | 6300 | LED | 5.00 | 92900123 | ||||
FORCELED 6000 E3TX L840 | 53 | 6300 | LED | 5.20 | 92900132 | ||||
FORCELED 6000 HF E3 L840 | 53 | 6300 | LED | 4.60 | 96241955 | ||||
FORCELED 6000 HF E3 MWS L840 | 53 | 6300 | LED | 4.70 | 96242082 |
▼ ForceLED productos configurados, regulable, emergencia
Descripción | Potencia de la luminaria (W) | Salida lumínica (lm) | Tipo | Peso (kg) | Código SAP | ||||
---|---|---|---|---|---|---|---|---|---|
FORCELED 4000 HFI E3 L840 | 34 | 4150 | LED | 2.05 | 92900128 | ||||
FORCELED 4000 HFI E3TX L840 | 34 | 4150 | LED | 5.60 | 96617237 | ||||
FORCELED 6000 HFI E3 L840 | 53 | 6300 | LED | 5.20 | 92900119 |
▼ ForceLED productos configurados, función pasillo
Descripción | Potencia de la luminaria (W) | Salida lumínica (lm) | Tipo | Peso (kg) | Código SAP | ||||
---|---|---|---|---|---|---|---|---|---|
FORCELED 4000 COR MWS L840 | 34 | 4150 | LED | 2.70 | 96242078 | ||||
FORCELED 4000 COR MWS RF L840 | 34 | 4150 | LED | 3.20 | 92900111 | ||||
FORCELED 4000 COR MWS TW L840 | 34 | 4150 | LED | 3.20 | 92900136 | ||||
FORCELED 4000 COR RF L840 | 34 | 4150 | LED | 4.50 | 92900112 | ||||
FORCELED 4000 COR RF QC L840 | 34 | 4150 | LED | 3.03 | 92900113 | ||||
FORCELED 6000 COR MWS L840 | 53 | 6300 | LED | 4.75 | 92900115 | ||||
FORCELED 6000 COR MWS RF L840 | 53 | 6300 | LED | 2.70 | 96617238 | ||||
FORCELED 6000 COR MWS RF QC L840 | 53 | 6300 | LED | 5.50 | 92900114 | ||||
FORCELED 6000 COR RF L840 | 53 | 6300 | LED | 3.15 | 92900117 |
▼ ForceLED productos configurados, función pasillo, emergencia
Descripción | Potencia de la luminaria (W) | Salida lumínica (lm) | Tipo | Peso (kg) | Código SAP | ||||
---|---|---|---|---|---|---|---|---|---|
FORCELED 4000 COR MWS E3 L840 | 34 | 4150 | LED | 5.45 | 92900129 | ||||
FORCELED 4000 COR MWS RF E3 L840 | 34 | 4150 | LED | 3.50 | 92900130 | ||||
FORCELED 4000 COR RF E3 L840 | 34 | 4150 | LED | 2.20 | 92900131 | ||||
FORCELED 6000 COR MWS E3 L840 | 53 | 6300 | LED | 3.08 | 92900120 | ||||
FORCELED 6000 COR MWS E3TX L840 | 53 | 6300 | LED | 4.75 | 92900175 | ||||
FORCELED 6000 COR MWS RF E3 L840 | 53 | 6300 | LED | 4.75 | 92900121 | ||||
FORCELED 6000 COR RF E3 L840 | 53 | 6300 | LED | 5.20 | 92900122 |
